The steam engine familiarly explained and illustrated; with an historical sketch of its invention and progressive improvement; (1836)
Lardner, Dionysius, 1793-1859, Renwick, James, 1790-1863. [from old catalog] · Philadelphia, E. L. Carey & A. Hart · leaf 209
he Rocket,on each side of the boiler; each working a separate wheel, 174 THE STEAM ENGINE. but acting on spokes placed at right angles to eaeh other.The tube in which the grate and flue are placed diminishesin diameter as it approaches the chimney. At the mouthwhere the grate was placed, its… … LOCOMOTIVE ENGINES ON RAILWAYS. 175 of the fire was 16 square feet; and that exposed to the ac-tion of the heated air and flame was about 75 square feet.The magnitude of the grate or sheet of burning fuel whichradiated heat, was 10 square feet. (90.) The Novelty, of Messrs. Braithwait and…
Steam-engines
