The steam engine familiarly explained and illustrated; with an historical sketch of its invention and progressive improvement; (1836)
Lardner, Dionysius, 1793-1859, Renwick, James, 1790-1863. [from old catalog] · Philadelphia, E. L. Carey & A. Hart · leaf 254
isible in fig. 62, at c. The otherextremities of these tubes at a are connected with the samenumber of upright tubes, one of which is expressed at e.The upper extremities a of these upright tubes are connectedwith another set of tubes k, equal in number, proceeding LOCOMOTIVE ENGINES ON TURNPIKE… … Fig. 63. a E t D > o r^- Z^Qa S= TT? OTa 220 THE STEAM ENGINE. tween the cylinders d and h there are two tubes of communi-cation b, and two similar tubes between the cylinders h and i.From the nature of the section these appear only as a singletube in fig. 62. From the top of the cylinder i…
Steam-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
