Fig. 16 Eccentric Circle Showing RelativePositions of Crank and Eccentric 1 \ 1 p, % ii 4 /£ 1 i … tfw- Fig. 17. Diagram for Finding Displacement of Piston horizontal position, the point R would describe the arc of a circleRN, and X N would represent the piston displacement and wouldbe equal to A Px. Suppose now that in this disconnected way, the 14 VALVE GEARS piston, crosshead, and connecting…
