Ludy, Llewellyn V., 1875- [from old catalog], American Technical Society · Chicago, American technical society · leaf 120
VALVE GEARS 17 a proper proportion between the rocker arms, and a careful locationof the pivot of the rocker. The eccentric must then be set accord-ingly. In this manner, the Straight Line engine equalizes the cut--off and lead. A discussion of this method will be considered later. VALVE DIAGRAMS… … Fig. 22. Zeuner Diagram for Valve Analysis a knowledge of the valve motion without the complex mathematicalexpressions that such a discussion would entail. The most usefulof these various diagrams is that devised by Zeuner and, to avoidcomplexity, we shall confine ourselves to a discussion of this…
Indicators for steam-engines · Steam-engines
