Ludy, Llewellyn V., 1875- [from old catalog], American Technical Society · Chicago, American technical society · leaf 13
rt gear. 67 Double valve gears 73 Meyer valve 73 Shifting eccentric valve gear 78 Thompson automatic valve gear 81 Drop cut-off gears 85 Reynolds-Corliss gear 86 Nordberg gear 89 Brown releasing gear 90 Greene gear 91 Sulzer gear 92 Corliss valve setting 92 Adjusting steam lap 93 Adjusting exhaust… … PART I STEAM ENGINE INDICATORS INTRODUCTION The steam engine indicator is an instrument designed to makean accurate graphical diagram of the pressure of the steam in theengine cylinder at all points of the stroke. This diagram affords ameans for studying the performance of the steam engine. . The…
Indicators for steam-engines · Steam-engines
