Ludy, Llewellyn V., 1875- [from old catalog], American Technical Society · Chicago, American technical society · leaf 196
Fig. 83. Form of Vacuum Dashpot forClosing Admission Valves VALVE GEARS 93 Wfi/STPLATBSTAND … Fig. 84. Corliss Wrist Plate for AdjustingCarrier Rod arm swings equal distances on each side of a vertical line throughits pivot, and the carrier rod should be adjusted until the wrist plateoscillates symmetrically about a vertical line through its pivot.Nearly all Corliss engines have one mark on…
Indicators for steam-engines · Steam-engines
