Ludy, Llewellyn V., 1875- [from old catalog], American Technical Society · Chicago, American technical society · leaf 32
Fig. 21. Indicator Card Showing Effect ofChanging Connecting Pipe It is hoped that what has been said is sufficient to point out theimportance of the short indicator connection. Continuous Diagrams. From the study of the indicator, ithas been obvious that the indicator card gives an indication of… … Fig. 22. Indicator Card Showing Effect ofChanging Connecting Pipe that are to be relied upon when the engine is working under con-stantly varying conditions, as in gas engines, locomotives, marineengines, and rolling-mill engines. To meet this demand, an attach-ment has been developed whereby it is…
Indicators for steam-engines · Steam-engines
