diation. The outlet pipe Nshould be at least 1 inch in diameter for its entire length and it maybe larger. To use the calorimeter, fill the thermometer well T with oil ormercury and then insert the thermometer. Attach the gauges andpermit steam to enter the cylinder K until, say, about 5 pounds… … STEAM ENGINE INDICATORS 59 the apparatus for about ten minutes before taking observations.The observations to be taken are the pressure P of the steam in themain steam pipe, the pressure Px of the steam in the calorimeter,the temperature t in the calorimeter, and the barometric pressure P .Having…
