Ludy, Llewellyn V., 1875- [from old catalog], American Technical Society · Chicago, American technical society · leaf 85
Fig. 57. Card Showing Effect of Changing Cut-Off Faulty Valve Arrangement. A typical card taken from a StraightLine engine, running at 270 r.p.m. at full load, is shown in Fig. 59. 72 STEAM ENGINE INDICATORS Aside from illustrating the form of card that this particular type ofengine gives, it is of… … Fig. 58. Effect on Card by Throttling the Engine at the end of the stroke as indicated at a. Late admission is indi-cated by the sloping admission line, giving the space b between the
Indicators for steam-engines · Steam-engines
