Creighton, William Henry Paul, 1859- · New York, J. Wiley & sons; [etc., etc.] · leaf 427
At Top Fig. 222. … Curve of Displacement 225. Figs. 223, 224, The following description is taken from Vol. XXII, Trans.A. S. M. E. The method of obtaining the crank diagram will beomitted, as the only practical difference between the authorsmethod and our own is that he uses the total pressure on thepiston of each…
Steam-engines · Heat-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
