Fig. 75.€iXC2; lay off cut-off points B and B and find crank positions02 and 02; lay off XA = l/4 and obtain 04 crank position atsteam admission and prolong, thus obtain 03, a tangent to the Fig. 76.lap circle, head end; the maximum port-opening, head end, beinggiven, layoff arc SS with a radius =…
