Creighton, William Henry Paul, 1859- · New York, J. Wiley & sons; [etc., etc.] · leaf 385
diagram for the main valve as usual, BOP beingthe angular advance, Pe and Pi being the exhaust- and steam-laps.With a center C0 and a radius equal to the negative lap of the cut-off valve describe a circle tangent to OA. Draw any crank posi-tion 07. Drop the perpendicular C08. Then from the… … Fig. 193. open, the negative lap, and at OA the port is clored. If the port inthe main valve is closed, it is a matter of indifference whether theport in the cylinder is open or closed. If the eccentric center isrotated to Cu then the cut-off is in crank position 02. The latestdesirable cut-off…
Steam-engines · Heat-engines
