Steam engines, a thorough and practical presentation of modern steam engine practice (1920)
Ludy, Llewellyn V., 1875-, American Technical Society · Chicago, American technical society · leaf 142
ce condenser,or mingle with a spray of water, as in a jet condenser. These twotypes will now be discussed. Types of Condensers. Condensers may be divided into twogeneral classes as follows: (1) Surface condensers in which the cooling water is separatedfrom the steam, usually by metallic surfaces in… … 77. Diagram Show : Relation of Surface Condenser to the Pumpa Necessary forProper Operation condensers, ejector condensers, etc., in which the cooHng watermingles with the steam to be condensed. Surface TypCi The condenser shown in section in Fig. 76 is oneform of the surface type, in which the air…
Steam-engines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
