Ripper, William, 1853-1937 · London, New York [etc.] : Longmans, Green and co. · leaf 430
zzle, which is or may be looked upon as the extremityof a convergent nozzle preceding it, and where the pressure of thesteam approaches its critical value ; {1) a divergent part, in which thesteam expands to its terminal pressure ; (3) a parallel part, in whichthe steam-particles are directed in… … A, Stonm stop valve; B. steam chest cover: C, steam sieve; D, srovernor vaTve orthrottle valve; E, steam chest; F, turbine wlieel ; G. shaft for belt iiulley;H pinion- J, searinp wheel; L, flexible shaft; M, belt pulley; N, exhaustoutlet- O, cover for exhaust chamber; P, ball bearin-s: K. exhaust…
Steam-engines
