Ripper, William, 1853-1937 · London, New York [etc.] : Longmans, Green and co. · leaf 91
Fig. 73. … J Fig. 74. THE SLIDE-VALVE. n Tlien for crank-pin position C, eccentric position is at D. Startinf from D, divide tlie eccentric circle into the same number of equal parts, r, 2, etc., as on the crank-pin circle. Draw liorizontals from the eccentric positions to in tersect verticals from the crank…
Steam-engines
