ets of experiments fully represent the data nowavailable, and comprise the greater part of this body of information.They are those of Callendar and Nicholson, made at McGill Univer-sity in 1895, Proc. Inst. C. E., 1898, vol. 131, pages 147 to 268; andof Duchesne, at the University of Liege from… … O M 33 30 21 24 21 N Fig. 119. — Typical Indicator Diagrams, prepared for plot of temperature curves. be derived from the indicator diagram. In Fig. 119 the three diagramsgiven cover a wide range of power development, showing a steam dis-tribution of the constant-compression type, as by the Corliss…
