The steam engine and turbine; a text-book for engineering colleges (1911)
Heck, Robert Culbertson Hays, 1870- · New York, D. Van Nostrand company · leaf 422
Fig. 266. — Cross Section of the Cylinder in Fig. 265. Upper right-hand quartertaken at mid-length, the rest of the section through -the head-end ports. The result sought and obtained is, that the valve shall have a widerand quicker movement in the direction for opening, a shorter andslower… … Fig. 267. — Corliss Valve Gear, Single-eccentric Type, with Full Wrist Plate. 1. Eccentric rod. 2. Rocker arm. 3. Reach rod. 4. Wrist plate. 5. Steam-valve rods. 6. Oscillating cranks. 12. 7. Exhaust-valve rods. 13. 8. Exhaust-valve arms. 14. 9. Steam-valve arms. 15. 10. Hook claw. 16. 11. Cam…
Steam-engines · Steam-turbines
