The steam engine and turbine; a text-book for engineering colleges (1911)
Heck, Robert Culbertson Hays, 1870- · New York, D. Van Nostrand company · leaf 400
c through the rod pins and the centerarc of the slot. This particular degree of curvature therefore reducespractically to zero any effect which the shape of the link might haveupon valve position, and leaves the mechanism free to reproduce andcombine, at the block, the motion of the eccentric… … Fig. 243. — The Direct Link Motion. into the characteristic locomotive position. The effect of the reversingrocker arm, as set forth in Fig. 229, and further indicated by the dotted-line eccentric settings in Fig. 240, is here shown in the reversed positionof the crank, with reference to the figure…
Steam-engines · Steam-turbines
