The steam engine and turbine; a text-book for engineering colleges (1911)
Heck, Robert Culbertson Hays, 1870- · New York, D. Van Nostrand company · leaf 41
Fig. 20. — Section of a 24-stage Rateau Turbine, in three steps and two cylinders;500 horse-power at 2400 r.p.m.; mean diameter of vane rings, 20 in. to 33 in.;vane velocity, from 220 to 345 ft. per sec. … Fig. 20. — Continued. Low-pressure section or cylinder of the turbine, on sameshaft with high-pressure section. more room, because of the expansion of the steam. In Fig. 19 thescheme of partial peripheral admission, with increase in width of nozzleopening, is shown. The second part of Fig. 20 shows…
Steam-engines · Steam-turbines
