The steam engine and turbine; a text-book for engineering colleges (1911)
Heck, Robert Culbertson Hays, 1870- · New York, D. Van Nostrand company · leaf 540
L … Fig. 366. — Built-up Nozzles. I, Zoelly design, Fig. 365; II,Type of Sulzer, Elektra, etc. join the rim and body of the partition disc. The detail of constructionis shown in Fig. 366 I. Inclined slots are milled (sawed) in the rim ofthe diaphragm wheel and the edge of the cover ring, and the…
Steam-engines · Steam-turbines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
