The steam engine and turbine; a text-book for engineering colleges (1911)
Heck, Robert Culbertson Hays, 1870- · New York, D. Van Nostrand company · leaf 72
- Mechanical Diagram forHeating at Constant Pressure andat Constant Volume. Fig. 35. — Thermal Curves forOperations in Fig. 34. 100 … 5 V 10 15 20 Fig. 36. — The Carnot Cycle as in Fig. 33. 800-600- 2 3 B 400- T- 200- 4A 0 1 1 1 1 1 1N 0.05 Fig. 37.— Temperature-Entropy Diagram forFig. 36. (c) Isothermal and Adiabatic Operations. — In the temperature-entropy system, or on the thermal side, the two simplest operations arethe…Steam-engines · Steam-turbines
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
