or slides to conduct the steam to and from the cylinder.If s represent a pipe conducting steam from the boiler, c theexhausting pipe, t the tube which leads to the top of thecylinder, and B that which leads to the bottom, then when thecock is in the position (fig. 23), steam would flow from the…
