Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 163
-Valve-Body -SfrainzrFig. 159.—Foot Valve With Stainer. … Hmgeo/ Rubber-Facec/ Va/vzs. Fig. 160.—A Foot-Valvesembled. (Strainer shownfrom seat-flange.) Disas-broken case it might be necessary to disconnect the pump for repairs.If the pump is required to lift its suction supply, a foot-valve(Figs. 159 and 160) should be connected to the inlet orifice ofthe…
Steam power plants · Pumping machinery
