Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 176
■Funnel … W-SMWRER&W&Q&m mm?m$ Fig. 177.—Illustrating The Principle Of The Injector. Note.—Ordinary injectors can discharge against a pressure greaterthan 130 per cent, of the steam-supply pressure. Special injectors areobtainable which will utilize exhaust steam at atmospheric pressure…
Steam power plants · Pumping machinery
