condensation of thesteam jet by the incoming water. If this water is too warm,the injector will not start. This limit is called the over-flowing temperature. After the injector has started, it ispossible to operate with an intake water of a higher tempera- 164 STEAM POWER PLANT AUXILIARIES [Div. 5… … 0 25 50 75 100 125 150 115 200 225 250 215 300 325Steam Pressure in Lb. per So). Inch Fig. 183.—Limiting And Overflowing Temperatures. (This figure was takenfrom page 135 of Kneass Practice And Theory op the Injector.) peratures affect delivery temperature of feed-water, capacity of injectorand…
