Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 425
urn traps (Fig. 400) or those which discharge against normalatmospheric pressure, or into receptacles under less than boiler pressure. Steam Traps May Be Classified According To The PrinciplesOf Operation Chiefly Employed as: (1) Buoyancy traps, which com-prise ball-float traps (Fig. 396, 400 and… … Water Column Strainer-*-- ■Alloy Expansion Tube Fig. 395.—Kieley Expansion Intermittent-Discharge Steam Trap Draining Radia-tion. When T Fills With Water And Cools, It Contracts And Draws In H And P.V Is Then Opened By Upward Thrust Of S Against L. When Steam Enters, T Ex-pands And Pushes Out H And…
Steam power plants · Pumping machinery
