Steam power plant auxiliaries and accessories; (1922)
Croft, Terrell, 1880- ed, Dufflin, Daniel John, 1911- ed · New York, [etc] McGraw-Hill book company, Inc · leaf 97
Fig. 85.—Horizontal Section Of A Double-Acting Duplex Crank-And-Fly-Wheel Pump. Connecting … Fig. 86.—Crank-Action Pump Of The Walking-Beam Type (Pumps Of This Type AreNow Practically Obsolete). 84. In The Operation Of Crank-And-Fly-Wheel Pumps the steam is worked expansively in the driving cylindersinstead of being admitted during the entire stroke of the piston(Sec. 90), as in the…
Steam power plants · Pumping machinery
Internet Archive · Library of Congress · Public Domain Mark 1.0. Free to use for anything.
