Steam turbine engines : their construction, care and operation (1910)
Swingle, Calvin F. (Calvin Franklin), b. 1846 · Chicago : Frederick J. Drake · leaf 66
Fig. 2fn DE LAVAL NOZZLE principles of the De Laval expanding nozzle are in factmore or less prominent in all steam turbines. The facilitiesfor converting heat into work are increased by its use, and Tlie De Laval Turhine 61 the losses by radiation and cooling influences are greatlylessened. The De… … Fig. 268the de laval turbine wheel and nozzles has been found to be best adapted for receiving the im-pulse of the steam jet. There are no stationary or guideblades, the angular position of the nozzles giving directionto the jet. Fig. 268 shows the form of wheel and thenozzles. The nozzles are…
Steam-engines -- Design and construction · Steam-turbines -- Handbooks, manuals, etc
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
