The student's instructor in drawing and working : the five orders of architecture : fully explaining the best methods for striking regular and quirked mouldings, for diminishing and glueing of columns and capitals, for finding the true diameter of an order to any given height, for striking the ionic volute, circular or elliptical, with finished examples, on a large scale, of the orders, their planceers, etc. and some designs for door-cases (1837)

Nicholson, Peter, 1765-1844 · New York : Office of the Railroad Journal · leaf 107

An illustration from The student's instructor in drawing and working : the five orders of architecture : fully explaining the best methods for striking regular and quirked mouldings, for diminishing and glueing of columns and capitals, for finding the true diameter of an order to any given height, for striking the ionic volute, circular or elliptical, with finished examples, on a large scale, of the orders, their planceers, etc. and some designs for door-cases, 1837, leaf 107
CORINTHIAN CAPITAL.Plate 8 1. … 37 OF THE CORINTHIAN ORDER. PLATE XXXI. Is the Corinthian capital and plan in outline for the sake of clearness ; to find theplaces of the stems of the leaves, divide the semi-plan into eight equal parts, and drawthe plan of the leaves, with their stems ; from the side of each stem draw the…

Architecture

Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
