The student's instructor in drawing and working : the five orders of architecture : fully explaining the best methods for striking regular and quirked mouldings, for diminishing and glueing of columns and capitals, for finding the true diameter of an order to any given height, for striking the ionic volute, circular or elliptical, with finished examples, on a large scale, of the orders, their planceers, etc. and some designs for door-cases (1837)

Nicholson, Peter, 1765-1844 · New York : Office of the Railroad Journal · leaf 113

An illustration from The student's instructor in drawing and working : the five orders of architecture : fully explaining the best methods for striking regular and quirked mouldings, for diminishing and glueing of columns and capitals, for finding the true diameter of an order to any given height, for striking the ionic volute, circular or elliptical, with finished examples, on a large scale, of the orders, their planceers, etc. and some designs for door-cases, 1837, leaf 113
Plate 33. … 39 PLATE XXXIII. The Corinthian cornice, with the planceer inverted. The height and projections ofthe cornice are the same as in Plate XXXII. 40 PLATE XXXIV. Is the manner of drawing the Corinthian column with an entablature entire ; or thecolumn and entablature on a pedestal; or upon a subplinth.…

Architecture
