The student's instructor in drawing and working : the five orders of architecture : fully explaining the best methods for striking regular and quirked mouldings, for diminishing and glueing of columns and capitals, for finding the true diameter of an order to any given height, for striking the ionic volute, circular or elliptical, with finished examples, on a large scale, of the orders, their planceers, etc. and some designs for door-cases (1837)

Nicholson, Peter, 1765-1844 · New York : Office of the Railroad Journal · leaf 59

An illustration from The student's instructor in drawing and working : the five orders of architecture : fully explaining the best methods for striking regular and quirked mouldings, for diminishing and glueing of columns and capitals, for finding the true diameter of an order to any given height, for striking the ionic volute, circular or elliptical, with finished examples, on a large scale, of the orders, their planceers, etc. and some designs for door-cases, 1837, leaf 59
THE DORIC ORDER WITH DENTILS.Plate 15. … 21 PLATE XV. Is another example of the Doric order ; with dentils in the cornice; and is very properfor the inside of a building, the column being fluted, and the whole much enriched. This example is after the manner of the Doric order in the theatre of Marcellus atRome. TO DRAW THE DORIC ORDER TO…

Architecture

Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
