The student's instructor in drawing and working : the five orders of architecture : fully explaining the best methods for striking regular and quirked mouldings, for diminishing and glueing of columns and capitals, for finding the true diameter of an order to any given height, for striking the ionic volute, circular or elliptical, with finished examples, on a large scale, of the orders, their planceers, etc. and some designs for door-cases (1837)

Nicholson, Peter, 1765-1844 · New York : Office of the Railroad Journal · leaf 86

An illustration from The student's instructor in drawing and working : the five orders of architecture : fully explaining the best methods for striking regular and quirked mouldings, for diminishing and glueing of columns and capitals, for finding the true diameter of an order to any given height, for striking the ionic volute, circular or elliptical, with finished examples, on a large scale, of the orders, their planceers, etc. and some designs for door-cases, 1837, leaf 86
antage over the others, it fronts each of itssides alike; which is not the case with the Grecian capital, unless one of the angles ishorned at the return of the building; which is unpleasing to some, and not consiceredas correct. 30 PLATE XXIV. Is the Ionic order with dentils in the cornice on an… … MODERNPlate IONIC. 25.

Architecture

Internet Archive · Getty Research Institute · Public Domain Mark 1.0. Free to use for anything.
