A system of geometry and trigonometry, together with a treatise on surveying ... Likewise, rectangular surveying ... To the whole are added, several mathematical tables, necessary for solving questions in trigonometry and surveying .. (1825)
Flint, Abel, 1765-1825 · Hartford, O. D. Cooke & co. · leaf 63
y small Bend. Fig, 68. Begin near one corner of theField, as at A, Fig. 68. andmeasure to the next large Cor-ner, as B, in a straight Line ;noticing also the Bearing ofthis Line, From the Linetake Offsets to the severalBends, at Right Angles fromthe Line; noticing in theField Book at what part… … FIELD BOOK. Bearing and Distance, Offsets Bearing and Distance. Ofiisets Ch. L. Ch. L. Ch. L. Ch. L. AB. N, 85° 0 E. 11.20 0.56 EF. S. 57° 50 W. 8.20 0,40 at 6.40 1.40 at 1. 4 0.36 8.26 0.36 2.96 0.33 the end 0.36 5.88the end 1.0 12 BC. N. 70 20 E. 7.96at 2.36 0.36 FG. S. 27° 40 E. 7.06 1.20 4.28…
Surveying
