positions on each pick, the greater pull will be with thetop part of the shed in the direction of E, or, if wovenface down, in the direction of E^. Following out theabove remarks, the best result for such designs w^ould beto incline the reed at such an angle which will oppose thedirection of the… … Fig. 12. pick is being inserted. It wih be observed, therefore,that the position of the reed in looms engaged in theweaving of cloths constructed from designs A, C, D, thebest position for the reed at the beat-up will be themedium position as shown in Fig. 11. The foregoingremarks also apply to…
