Technology of textile design. Being a practical treatise on the construction and application of weaves for all textile fabrics, with minute reference to the latest inventions for weaving. Containing also an appendix showing the analysis and giving the calculations necessary for the manufacture of the various textile fabrics (1889)
Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, Pub. by the author [etc.]; London, S. Low, Marston, Searle & Rivington, limited · leaf 183
Fig. 820. pile loops can be formed, each wire being pivoted at right angles to the plane of its longitudinalmovement and provided with means for depressing its free end at proper intervals, so as to engagebeneath the warps which are to form the pile. In Fig. 818 an exterior side-view of a loom… … Fig. 821. which are well understood in their action and whose insertion in the drawings would only tendto confuse the mind, and render a comprehension of the special parts to which the presentarrangement relates, less clear. Fig. 819 is a view in detail of a portion of the sectional wire which…
Textile fabrics
Internet Archive · Clark Art Institute Library · Public Domain Mark 1.0. Free to use for anything.
