Technology of textile design. A practical treatise on the construction and application of weaves for all textile fabrics... Containing also an appendix describing all the latest methods and improvements in designing and manufacturing (1890)

Posselt, E. A. (Emanuel Anthony), 1858-1921 · Philadelphia, E.A. Posselt; London, S. Low, Marston · leaf 211

An illustration from Technology of textile design. A practical treatise on the construction and application of weaves for all textile fabrics... Containing also an appendix describing all the latest methods and improvements in designing and manufacturing, 1890, leaf 211
separate pile-cloths as shown at N N. Fig. 854 illustrates a plan-view of part of a loom having the before-mentioned arrangementattached. Fig. 855 is a front elevation, with the bracket, which supports the operating shaft as well asthis shaft and its driving-pulley and bevel-gear, removed. Fig. 856… … I. \ YW!fc

Textile fabrics
