A text book of geometrical drawing : abridged from the octavo edition : for the use of schools in which the definitions and rules of geometry are familiarly explained, the practical problems are arranged from the most simple to the more complex, and in their description technicalities are avoided as much as possible : with an introduction to isometrical drawing : and an essay on linear perspective and shadows ... (1849)
ired to lay off the side at right angles to it from thecorner D, 1st. Drive in a small stake at D, put the ring of a tape mea-sure on it and lay off twelve feet toward JB. 2nd. With a distance of sixteen feet, the ring remaining at D,trace a short circle on the ground at E. 3rd. Remove the ring to… … Fi/j. 2 .
