tchcircle on which the width of the teeth and spaces must be laiddown. Then with a radius D. E or D. F^ equal to a pitch anda fourth, from the middle of each tooth on the pitch circle as at D,describe the tops of the teeth E and Fy from 0 describe the topsof the teeth G and D, and so on for the… … Plate 35. TEETH OE WHEELS
