A text book of geometrical drawing, for the use of mechanics and schools, in which the definitions and rules of geometry are familiarly explained (1849)

Minifie, William, 1805-1880 · Baltimore, W. Minifie & co. · leaf 21

An illustration from A text book of geometrical drawing, for the use of mechanics and schools, in which the definitions and rules of geometry are familiarly explained, 1849, leaf 21
QIMJJPJRATERALS. OJJARPiANGLES OR TETRAGONS. PARALLELOGPiAMS-. … ir^Mirafio,. JUmaTikSoTis PLATE IL PLANE RECTILINEAR SUPERFICIES. 13. A Superficies or Surface is considered as an extension oflength and breadth without thickness. 14. A Plane Superficies is an enclosed flat surface that willcoincide in every place with a straight line. It is a succession…

Mechanical drawing · Geometry, Descriptive · Perspective
