FiG. 347. nally according to a definite scheme depending on the shape ofthe magnet, the position of its poles, etc. Figs. 346-349 repre-sent magnetic fields in special well defined cases. In Fig. 346 … wm Fig. 348. MAGNETIC FIELDS. 481 the field is produced by a single straight bar magnet with thepoles near the ends. Fig. 347 shows the field looking end-on-towards a bar magnet. Fig. 348 represents the field between thepoles of two such magnets with unlike poles opposed. Fig. 349shows the field…
