A text book of physics, for the use of students of science and engineering (1918)
Duncan, John, d. 1941, Starling, Sydney George, 1873- · London Macmillan · leaf 1019
■-> -X -4- i !■ 986 3i le wound field magnet. … FIG. 037.—Shunt wound field magnet. forms, one form being that given in Fig. 036. Here the currentflowing in the field coils, which causes the magnetisation, flows alsoin I he external circuit. The field coils are thus in series with thearmature and the external circuit. When this arrangement…
