A text book of physics, for the use of students of science and engineering (1918)
Duncan, John, d. 1941, Starling, Sydney George, 1873- · London Macmillan · leaf 893
e range. Without the cylinder Athe field would no longer be radial, so that when the coil rotates itwould be differently situated with respect to the magnetic field. Thelaw connecting deflection and current would then be more complex. In Fig. 799 a suspended coil galvanometer is illustrated whose… … Fig. 800.—Suspended coil galvanometer with bifilar suspension. of suspension is shown in Fig. 800. The magnet is vertical and thecoil is circular. The most important difference between this and the previous type is in the suspen-sion, which is bifilar. The currentcomes down one…
Physics
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
