Merriman, Mansfield, 1848-1925, Jacoby, Henry Sylvester, b. 1857 · New York Wiley · leaf 277
\, and y.^ completely determine the recti-linear sides of the special equilibrium polygon for a singleconcentrated load P. The line a^d represents the line ofaction of the left reaction R^ whose magnitude is given in the … Fig 133- force polygon at the right in Fig. 133. If i\ be the length ofthe perpendicular from the center of the left support to theline a^d, the moment at that support is J/j = R^j\- If A\ be Art. 95. THE PARABOLIC ARCH RIB. 263 resolved into its components / \ and //, the lever arm of J\ iszero…
Bridges · Roofs
Internet Archive · Gerstein Library, University of Toronto · Public Domain Mark 1.0. Free to use for anything.
