he design therefore = 84 mails : 70 ends :: 384 hooks : 320 JACQUARD, HARNESS, AND DESIGN CALCULATIONS 225 ends; and the cast out = 384 - 320 = 6i ends. The horizontal ground figurewas designed upon 320 ends, and the extra warp stripe upon 64 ends, the completedesign thus occupying 384 ends for the… … 60 extra warp eSect, were cast out; but where the extra warp figure was introducedthe mails for it were filled in, and a corresponding number of ground mails cast out.Further, m figuring with two colours of warp arranged 1-and-l in the harness itIS possible by casting out an odd number of mails to…
