arries the rags forward totwo fluted steel rollers set to feed and hold the materials against theswift or cylinder, clad with serried rows of teeth. Above is the bit-roller, spiked to catch the broken bits of rags and throw them backon to the feeder; farther back is the second bitter, in the form… … Fig. s.—Rag-grinder, with Cover removed to show Working Parts F, Endless feed lattice, r r, Fluted feed rollers, b. Front bit-roller with spikes, t, Back bitter, or bit guard. S, Swift, or cylinder is varied by change wheels, according to the staple of materialrequired. Driven at speeds ranging…
