The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing (1910)
Murphy, William S · London : The Gresham Publishing Company · leaf 155
weaving are aptto be misled by thecharacter of the healds, as now formed. It must never be forgottenthat the essential and necessary nature of a heald is a series of warpcords. Suppose, for the sake of illustrating the fact, we undertaketo make up a heald. Taking a pair of wooden shafts, we fix… … Fig. 226.—Shedding Mechanism A, Treadles. b, Long lambs. c. Short Iambs. D, Heddles. E, Jacks.F, Short cords. G, Long cords. H, Streamer cords, j, Mails. THE PLAIN LOOM AND ITS DEVELOPMENT 117 eyelet is in the centre between the shafts. Close up to the first cordwe extend a second, taking care that…
Textile industry · Textile fabrics
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
