Under each needle bar, or bars, was fixed a long rod, thefingerlike end of which lay in a groove of a disc at the side of the loom.The disc contained the design of the lappet. It was made of some hardwood, because the stress to which the grooves in it were subjectedwas sometimes severe, and the… … Fig. 240.—Lappet Frame A, Lappet disc. B, Hammer, driving the disc one tooth at each stroke. c, Projecting portion of shifting-rodof needle frame. d, Handle of needle frame. e, Spring and cord to adjust tension of disc. a figure or other ornament upon the cloth. While moving forward with the batten…
