The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing (1910)

Murphy, William S · London : The Gresham Publishing Company · leaf 146

An illustration from The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing, 1910, leaf 146
greater force upon it; in order to effect that purposethe curve of the tappet must incline towards the cone (fig. 320). THE WEFT MECHANISM 117 The tappet has a blunt point which impinges directly upon the sideof the cone, driving it sharply. Shaping the tappet will thus be seen to be a matter of… … Plan op Tappeton linl x,x. E, Sword. F, Shuttle race,normal position after stroke. Iig. 320.—Cone Picking Motion: End of the StrokeG, Reed, h, Low shaft. I, Tappet, k, Cone. which appears best for picking. A more scientific method, however,and one likely to bring the best results and save time, is…
