The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing (1910)
Murphy, William S · London : The Gresham Publishing Company · leaf 73
eadily.Hooks.—Formed otiron wire, the hooks arebent at both ends, theupper end being curvedinto a shallow hook suf-ficient to grip on to thelifting griffe, while thelower end is a hook about11 in. long, because de-signed to hold securelythe heald or neck-healdcord of the warp. Thesize of the… … Fig. 284.—Jacquard Mechanism A, Cylinder. B, Needles. c, Hooks. D, Springs to keep the needlesin contact with the cylinder. E, Cards. F, Griffe knives. G, Grid. H,Bottom board, j, Griffe block. K, Arm, carrying the cylinder. L, Hammer,having a spring on its shank to steady the cylinder. M, Bowl on…
Textile industry · Textile fabrics
Internet Archive · UMass Dartmouth, Claire T. Carney Library · Public Domain Mark 1.0. Free to use for anything.
