The textile industries : a practical guide to fibres, yarns & fabrics in every branch of textile manufacture, including preparation of fibres, spinning, doubling, designing, weaving, bleaching, printing, dyeing and finishing (1910)
Murphy, William S · London : The Gresham Publishing Company · leaf 84
ig. 286.—Piano Cutter: Side Elevation and Plan A, Headstock. b, Spindles, c, Puncher, d. Lock-nut of crosshead. e, Pin. f, Centre lever, g, Link, h, Three-armed lever. I, Fulcrum of lever. j j, Connecting rods. K K, Treadles. L, Fulcrum of treadles. M, Carriage.N, Pins of rack. o, Slip catch. p.… … PIANO CARD-CUTTING iMACIIINE(Devoge & Co., Manchester) THE JACQUARD 65 cylinder. Under the thirteenth key is a thicker punch, designed tomake the holes for the cylinder pegs. The heads of the punches arecarried in a plate attached to the headpiece, and may be lifted clearout of touch with the…
Textile industry · Textile fabrics
